Brand	ABB
Impulse Withstand Voltage (kV/1.2µS)	4
AC Voltage (V)	400/415
Breaking Capacity (kA)	10 @415 V AC
Breaking Capacity 415V AC - Icu (kA)	10
Current Rating (A)	10
Curve Type	C Curve
Degree of Protection	IP20
Dimensions (mm)	36Wx86Hx70D
Family	S203C
No. of Poles	3P
Operational Temperature Range (°C)	-25 to +55
Poles	3P
Rated Current (A)	10
Rated Frequency (Hz)	50/60
Rated Impulse Withstand Voltage (kV)	4
Rated Operational Voltage AC (V)	415
Series	S203C
Trip Curve	C Curve

DIN MCB

ABB MCB, 10kA 3 POLE 10A C-CURVE 415V AC S203C-C10
