IPD TLU630 FUSE LINK 630A 660VAC CENTRE TAG 149mm FIXING CENTRES 80kA 400326

Product Code: TLU630

TLU centre bolted tags-4hole fixing BS fuse links (size D1) are designed for general industrial applications. They meet the standards of BS88-2 and IEC 60269-2. These fuse links have a breaking range and utilisation category of gG, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified to 80 kA. They have a rated current of 630A and can handle voltages up to 660VAC/350VDC.

Technical Specifications

Body Diameter (mm) 83.3
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Utilisation Category gG
Brand IPD
Carton Quantity 1
Fixing Centres (mm) 149
Rated Current (A) 630
Rated Voltage AC (V) 660
Rated Voltage DC (V) 350
