MERSEN A4J450 FUSE LINK 450A 600VAC 300VDC CLASS J FAST ACTING 64X95mm BOLT-IN

Product Code: A4J450

The A4J Fast-acting Class 'J' ferrule type fuses provide exceptional current-limiting protection for a range of applications including capacitors, load centers, panelboards, switchboards, busducts, feeder circuits, circuit breakers, lighting, heating, and general loads. These fuses have a voltage rating of 600VAC/300VDC and a rated current of 450A.

Technical Specifications

Brand MERSEN
Body Style Bolted Tag
Fuse Class Class J
Interrupting Rating AC (kA) 200
Interrupting Rating DC (kA) 100
Body Size (mm) 64 x 95
Functionality Fast Acting
Rated Current (A) 450
Rated Voltage AC (V) 600
Rated Voltage DC (V) 300
