IPD TB50 FUSE LINK 50A 690VAC CENTRE TAG 97mm FIXING CENTRES 80kA USE IN CM/CMS100, 400249

TB centre bolted tags-2hole fixing BS fuse links are designed for general industrial applications. They come in sizes B1 to B4, C1 to C3, and D1. These fuse links comply with the standard BS88-2 and IEC 60269-2. They have a breaking range and utilisation category of gG, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified to 80 kA. The rated current is 50A, and the voltages are 690VAC/460VDC.
