IPD TIA32M50L FUSE LINK 50A 415VAC OFF-SET TAG MOTOR RATED 73mm FIXING CENTRES 80kA USE IN RS32/63,RSM

Product Code: TIA32M50L

The TIA_L offset bolted tags-2hole fixing BS fuse links, available in sizes A1 to A4, are designed for general industrial applications. They comply with the standard BS88-2 and IEC 60269-2. These fuse links have a breaking range and utilisation categories of gM, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified to 80 kA. The rated current is 50A and the voltage is 415VAC.

Technical Specifications

Body Diameter (mm) 23.0
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Utilisation Category gM
Brand IPD
Carton Quantity 10
Fixing Centres (mm) 73
Rated Current (A) 50
Rated Voltage AC (V) 415
