IPD TM355L FUSE LINK 355A 415VAC CENTRE TAG 133/184mm FIXING CENTRES 80kA

Product Code: TM355L

TM_L centre bolted tags-4hole fixing BS fuse links (in sizes C1 to C4) are designed for general industrial applications. They comply with the standard BS88-2 and IEC 60269-2. The breaking range and utilisation categories are gG, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified to 80 kA. These fuse links have a rated current of 355A and a voltage of 415VAC.

Technical Specifications

Body Diameter (mm) 61.1
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Utilisation Category gG
Brand IPD
Carton Quantity 1
Fixing Centres (mm) 133/184
Rated Current (A) 355
Rated Voltage AC (V) 415
