ELKO VS425-04/230V DIN CONTACTOR 4NC, 25A (AC-1), CONTROL 230V AC/DC

Product Code: VS425-04/230V

The Din Contactor is a 4NC contact type with a current rating of 25A (AC1) and a control voltage of 230V AC/DC. It has a width of 2 modules, with each module being 17.5mm wide. The contactor provides IP20 protection and is designed for switching resistive loads and three-phase induction motors. It is suitable for various applications including heating, lighting, hot water, and storage heating. The Din Contactor can be easily mounted on a DIN Rail.

Technical Specifications

Brand ELKO
Contacts 4NC
Degree of Protection IP20
Dielectrical Strength (kV) 4
Dimensions (mm) 35 x 85 x 60
Mounting Type DIN Rail
No. of Modules - Width 17.5 mm 2
No. of Poles 4P
Operational Temperature Range (°C) -5 to +55
Rated Insulation Voltage (V) 440
Rated Operational Current AC-1 (A) 25
Rated Supply Voltage AC/DC (V) 230
Series VS
