ABB ESB63-22N-06 INSTALLATION CONTACTOR (NC) 30 A - 2 NO - 2 NC - 230 V - CONTROL CIRCUIT 400 HZ ESB6322N06

Product Code: ESB6322N06

  • Operates seamlessy with both AC and DC power sources Quiet and efficient operation Integrated overvoltage protection Customisable configuration
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Modules - Width 17.5 mm 3
Width in Number of Modular Spacings 3
Mounting Type DIN Rail
Operational Temperature Range (°C) -25 to +55
Brand ABB
Product Type DIN Contactor
Series ESB
Excitation Voltage Type AC/DC
Hum-free Yes
No. of Normally-closed Contacts 2
No. of Normally-open Contacts 2
Operating Voltage Type AC/DC
Rated Control Circuit Voltage (V) 230
Rated Control Circuit Voltage AC/DC (V) 230
Rated Frequency (Hz) 50/60
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 500
Rated Operational Current (A) 63
Rated Operational Current AC-1 (A) 63 (NO) 30 (NC)
Rated Operational Current AC-3 230V (A) 30 (NO)
Rated Operational Power AC-3 230V (kW) 5 (NO)
Rated Operational Voltage AC (V) 400
Rated Operational Voltage DC (V) 220
Terminal Type Screw
Dimensions (mm) 54W x 85H x 65D
Utilization Category AC-1 According to EN IEC 60947-4-1
Built-in Depth (mm) 58
Degree of Protection IP20
Pollution Degree 3

Description

The ESB63..N installation contactors are used to control single and three-phase loads up to 63 A and can be operated by AC or DC. These contactors are made for use in household applications as well as in industrial environments. The following benefits are provided: Hum-free operation, low power consumption and integrated overvoltage protection. Various contact combinations and accessories are available.
