ABB ESB20-11N-06 INSTALLATION CONTACTOR (NC) 20 A - 1 NO - 1 NC - 230 V - CONTROL CIRCUIT DC ESB2011N06
Zoom
Zoom
ABB ESB20-11N-06 INSTALLATION CONTACTOR (NC) 20 A - 1 NO - 1 NC - 230 V - CONTROL CIRCUIT DC ESB2011N06
Product Code: ESB2011N06
The ESB20..N installation contactors are used to control single loads up to 20 A and can be operated by AC or DC. These contactors are made for use in household applications as well as in industrial environments. The following benefits are provided: Hum-free operation, low power consumption and integrated overvoltage protection. Various contact combinations and accessories are available.
Technical Specifications
Built-in Depth (mm)
58
Excitation Voltage Type
AC/DC
Hum-free
Yes
Operating Voltage Type
AC/DC
Rated Control Circuit Voltage (V)
230
Rated Operational Current (A)
20
Rated Operational Current AC-3 230V (A)
9 (NO/NC)
Rated Operational Power AC-3 230V (kW)
1.3 (NO/NC)
Brand
ABB
Degree of Protection
IP20
Dimensions (mm)
18W x 85H x 65D
Mounting Type
DIN Rail
No. of Modules - Width 17.5 mm
1
No. of Normally-closed Contacts
1
No. of Normally-open Contacts
1
No. of Poles
2
Operational Temperature Range (°C)
-25 to +55
Pollution Degree
3
Rated Control Circuit Voltage AC/DC (V)
230
Rated Frequency (Hz)
50/60
Rated Impulse Withstand Voltage (kV)
6
Rated Insulation Voltage (V)
400
Rated Operational Current AC-1 (A)
20 (NO/NC)
Rated Operational Voltage AC (V)
250
Rated Operational Voltage DC (V)
220
Series
ESB
Terminal Type
Screw
Utilization Category
AC-1 According to EN IEC 60947-4-1
Width in Number of Modular Spacings
1
