ABB ATB503 ALUMINIUM TERMINAL BLOCK ACTIVE 6 CONNECTIONS CABLE 50mm²

Product Code: ATB503

The Aluminium Terminal Block is a versatile and efficient solution for electrical connections. It features 6 active connections and can accommodate cable sizes up to 50mm². The block is designed in a sleek grey colour, making it visually appealing. With a nominal current rating of 160A for copper cables and 145A for aluminium cables, this terminal block ensures reliable performance. It also has a nominal insulation voltage of 800V, providing safe operation. One of the key advantages of this terminal block is its compatibility with both copper and aluminium cables. This flexibility allows for easy installation and connection in various applications. To prevent galvanic reactions, the terminal block is tin plated. This coating enhances durability and ensures long-lasting performance. The internal barrier within the terminal block enables the connection of both aluminium and copper cables to a single block. This feature simplifies wiring processes and saves time during installations. With a screw head size of 5mm, the terminal block offers convenient assembly and disassembly. It is designed for din rail mounting, providing secure placement in electrical panels or enclosures. In summary, the Aluminium Terminal Block is a reliable and versatile solution for electrical connections. Its compatibility with different cable types, tin plating to prevent galvanic reactions, and internal barrier for connecting multiple cables make it an excellent choice for engineers seeking efficient wiring solutions.

Technical Specifications

Brand ABB
Colour Grey
Maximum Cable Cross Section (mm²) 50
No. of Connections 6
Nominal Current (A) 160 (Cu)/145 (AL)
Nominal Insulation Voltage (V) 800
Screw Head Size (mm) 5
Tightening Torque (Nm) 4 (2.5-4mm²)/12 (6-50mm²)
