Aluminium Terminal Blocks

ABB ATB2401E ALUMINIUM TERMINAL BLOCK EARTH 2 CONNECTIONS CABLE 240mm²

Product Code: ATB2401E

Aluminium terminal block with 2 earth connections. Can accommodate cable size up to 240mm² in yellow/green colour. Nominal current for copper is 425A and for aluminium is 380A. Nominal insulation voltage is 600V. Suitable for both copper and aluminium cables. Tin plating prevents galvanic reactions. Features an internal barrier that allows connection of aluminium and copper cables to a single block. Screw head size is 8mm. Designed for panel mounting.

Technical Specifications

Brand ABB
Colour Yellow/Green
Maximum Cable Cross Section (mm²) 240
No. of Connections 2
Nominal Current (A) 425 (Cu)/380 (AL)
Nominal Insulation Voltage (V) 600
Screw Head Size (mm) 8
Tightening Torque (Nm) 12 (35-70mm²)/45 (95-240mm²)
