Brand	ABB
Design of Control Element	Toggle
Magnetic - I3 (A)	1250
Main Circuit Electrical Connection	Bolt Connection
Main Current Circuit Connection Position	Front Side
MCCB Type	XT1 Frame
Rated Instantaneous Short-Circuit Current - Ii (A)	1250
Thermal (0.7 to 1 x In) - I1 (A)	87.5 - 125
Trip Unit - Thermal Magnetic	TMD
Tripping Unit	TMD
Breaking Capacity (kA)	36
Breaking Capacity 415V AC - Icu (kA)	36
Current Rating (A)	125
Degree of Protection	IP20
EAN	8015644013110
No. of Poles	3
Poles	3P
Power Loss (W)	10.7
Rated Current (A)	125
Rated Uninterrupted Current - Iu (A)	160
Rated Voltage (V)	690
Size of Frame	XT1
Trip Unit	TMD

Moulded Case Circuit Breakers

ABB XT1N 160 TMD 125-1250 3P F F 1SDA067417R1
