MERSEN 14G40 FUSE LINK 40A 500V AC/250V DC FERRULE 14X51mm 120KA X218198

The 14G' IEC cylindrical ferrule fuse links are designed to protect lines, cables, motors, and LV networks in electrical distribution circuits and industrial applications. They can limit and cut off overcurrents and short-circuit currents up to their nominal breaking capacity. These fuse links have a reduced size but provide full range protection. They belong to the gG utilization category and comply with standards IEC 60269-1&2 and BS88-1. The AC breaking capacity is certified at 120kA, while the DC breaking capacity is certified at 100kA. The rated current is 40A, with voltages of 500VAC/250VDC. The body size of these fuse links is 14x51 mm.
