IDEC 2-POLE TAB TERMINAL DIN 12V DC RELAY RL2B-D-D12

Product Code: RL2B-D-D12

The IDEC RL2B-D-D12 is a 12V DC relay designed for robust performance in controlling motor, lighting, and heater loads. It features double make contacts for reliable connectivity and switching. This 2-pole tab terminal DIN relay is also RoHS compliant, ensuring adherence to environmental standards. Ideal for industrial applications, it offers a compact solution for power management tasks.

Technical Specifications

Brand IDEC
Operating Time 30ms Max
Resistance to Shock (m/s²) 1000
Resistance to Vibrations 10 to 55Hz
Terminal Shape Quick Connect Terminal
Coil Voltage DC (V) 12
Contact Material Ag Alloy
Contacts 2X (DPST, Double Make)
Degree of Protection IP40
Dimensions (mm) 54W x 50H x 39.5D
Maximum Switching Current (A) 25
Minimum Mechanical Life 1,000,000
Mounting Type DIN Rail Mount with Panel Mount Tabs
No. of Poles 2
Operating Humidity 5 to 85%
Operational Temperature Range (°C) -25 to 55
Power Consumption (W) 1.9
Weight (g) 90-135
