Products

Outdoor Isolators & Socket Outlets

IPD IPW WEATHERPROOF ISOLATOR 1P 35A 240V PADLOCAKBLE, IP66 IPW351

Product Code: IPW351

IPW weatherproof isolator 1P 35A 240V padlockable, IP66. Max cable area 25mm² and 4 x M25 gland entries. Padlockable handle with front and rear entries and high strength locking screws. Includes earth & neutral terminals. Tested to IEC 60947.3 & AS3133. Dimensions 82.5Wx167Hx89Dmm and pack quantity is 20.

Technical Specifications

Brand IPD
Degree of Protection IP66
Dielectrical Strength (kV) 1
Dimensions (mm) 82.5W x 167H x 89D
Gland Entries 4 x M25
Maximum Cable Cross Section (mm²) 25
No. of Poles 1
Pack Quantity 20
Rated Current (A) 35
Rated Insulation Voltage AC (V) 500
Rated Short-Circuit Making Capacity - Icm (kA) 1.5
Rated Short-Time Withstand Current - Icw (kA) 0.76
Rated Voltage (V) 240
