IPD W66US315LB Unswitched Socket 3 Flat-Pin 1-Ph 15A 250VAC/DC IP66 Polycarbonate

Product Code: W66US315LB

  • 15A socket with flat pin type
  • IP66 rated for high protection
  • Complies with AS3112 standards
  • Durable polycarbonate construction
  • Supports up to 6 sq-mm cables
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Unswitched Socket
Brand IPD
Back Box Included No
Cable Cross Section 6 sq-mm
Cover Style Light Grey
Degree of Protection IP66
Depth 91 mm
Gland Entries (1) M32, (2) M25
Height 101 mm
Material Polycarbonate
Number of Pins 3
Phase 1
Pin Type Flat
Rated Current 15 A
Rated Voltage 250 VAC/VDC
Standards and Approvals AS3112
Width 101 mm

Description

<p>When selecting industrial and commercial-grade electrical components, reliability and compliance with standards are paramount. This socket is designed to meet the demanding needs of various applications, offering a robust solution for professionals in the field.</p><p>Engineered with precision, this socket features a rated current of 15 A, making it suitable for a range of electrical systems. It handles both AC and DC currents up to 250 volts, providing versatility for multiple setups. The product&amp;#39;s dimensions—101 mm in width, height, and 91 mm in depth—ensure it fits seamlessly into existing configurations without unnecessary bulk.</p><p>Constructed from durable polycarbonate material, this socket promises longevity even under challenging conditions. Its IP66 degree of protection safeguards against dust ingress and powerful water jets from any direction, making it ideal for outdoor or harsh indoor environments where exposure to elements is inevitable.</p><p>The socket adheres to AS3112 standards and approvals, ensuring compliance with Australian safety regulations—a critical factor when operating within legal frameworks that demand high safety levels. The flat pin type further complements its design by facilitating secure connections.</p><p>Installation flexibility is enhanced by the inclusion of various gland entries: one M32 entry alongside two M25 entries accommodate different cable sizes up to a cross-section of 6 sq-mm. However, note that the back box is not included; additional considerations may be needed during installation planning.</p><p>With these specifications in mind, this socket stands as a reliable choice for those seeking quality without compromise on performance or safety standards.</p>

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
