Product Code: W66SS410

This three-phase switched outlet features four round pins and a full-size back box. It has an IP66 rating, making it highly resistant to dust and water. The current rating is 10A, with a voltage rating of 500V. The maximum cable area supported is 6mm². It has one M32 entry and two M25 entries for easy installation. Made from polycarbonate UV stabilized material, it is durable and can withstand outdoor conditions. The stainless steel 316 fixings ensure secure fastening.

Brand	IPD
Back Box Included	Yes
Cover Style	Light Grey
Degree of Protection	IP66
Dimensions (mm)	101W x 197H x 110D
Gland Entries	1 x M32, 2 x M25
Material	Polycarbonate
Maximum Cable Cross Section (mm²)	6
No. of Phases	3
No. of Pins	4
No. of Poles	3
Pin Type	Round
Rated Current (A)	10
Rated Voltage AC/DC (V)	500
Standards and Approvals	IEC947-3/AS3133

W66 Industrial IP66 Switchgear

IPD SWITCHED OUTLET THREE PHASE 4 ROUND PINS 10A 500V, IP66 W66SS410
