W66 Industrial IP66 Switchgear

IPD SWITCHED OUTLET SINGLE PHASE 3 FLAT PINS 10A 250V, IP66 W66SS310

Product Code: W66SS310

Single phase switched outlet with 3 flat pins and shallow back box, IP66. Current rating at 10A, voltage rating at 250V. Max cable area 6mm² and 1 x M25, 2 x M20 entries. Polycarbonate UV stabilised material and stainless steel 316 fixings.

Technical Specifications

Brand IPD
Back Box Included Yes
Cover Style Light Grey
Degree of Protection IP66
Dimensions (mm) 101W x 197H x 85D
Gland Entries 1 x M25, 2 x M20
Material Polycarbonate
Maximum Cable Cross Section (mm²) 6
No. of Phases 1
No. of Pins 3
Pin Type Flat
Rated Current (A) 10
Rated Voltage AC/DC (V) 250
Standards and Approvals IEC947-3/AS3133/AS3112
