NOVARIS DIN MOUNT SINGLE PHASE SURGE FILTER, 32A SFD1-6-10-275

Product Code: SFD1-6-10-275

: The Novaris SFD1-6-10-275 is a compact, single-phase surge filter designed for protecting sensitive loads in space-restricted applications. It offers three stages of protection with varistor components and a low pass LC filter, housed in a durable metal enclosure.

Technical Specifications

Maximum Load Current - I? (A) 6
Brand NOVARIS
Degree of Protection IP20
Dimensions (mm) 18W x 69H x 115L
Maximum Continuous Operating Voltage MCOV AC (V) 275
Maximum Discharge Current (8/20µs) - Imax (kA) 10 kA (L-N, N-PE)
Mounting Type DIN rail
No. of Phases 1
No. of Poles 1P+N+PE
Nominal Discharge Current (8/20µs) - In (kA) 4 (L-N, N-PE)
Nominal Voltage AC (V) 230
Operational Temperature Range (°C) -40 to 70
Series SFD1
Standards and Approvals IEC 61643-11, AS/NZS 1768, UL 1449, IEEE 62.41.2
Voltage Protection Level - Up (kV) < 0.9 (L-N, N-PE)
Weight (g) 145
