<p>When it comes to safeguarding electrical systems, a reliable surge filter is essential. This particular surge filter offers robust protection for single-phase circuits with its 230 VAC rated voltage and 20 A rated current, making it suitable for various industrial and commercial applications. Designed to be mounted on a TS35 DIN rail or panel, this unit provides flexibility in installation.</p><p>The product&#39;s dimensions—115 mm in length, 72 mm in width, and 69 mm in height—ensure that it fits comfortably within most standard enclosures. Despite its compact size, the unit boasts a solid build with metal construction weighing in at 605 g. The IP20 degree of protection indicates it&#39;s designed for indoor environments where exposure to water is minimal.</p><p>A key feature of this surge filter is its LED status display, which offers an easy-to-read interface for monitoring operational status. It operates efficiently across a wide temperature range from -40 to 70 degrees Celsius and tolerates humidity levels between 5% and 95%, ensuring reliability under diverse environmental conditions.</p><p>For compliance assurance, it meets several international standards including IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 (3rd Edition), and IEEE 62.41.2:2002. These certifications underscore its capability to provide effective surge protection across different regions.</p><p>From a technical standpoint, the device features impressive response times of less than 100 nanoseconds (N-PE), offering rapid intervention during power surges. Its modes of protection include L-N (Line-Neutral), L-PE (Line-Protective Earth), and N-PE (Neutral-Protective Earth) configurations.</p><p>The lightning impulse current handling capacity stands at an impressive 3 kA for L-N connections and even more robust at 15 kA for N-PE connections. Additionally, the voltage protection level remains below &lt;600V (L-N), ensuring sensitive equipment stays protected during transient events.</p><p>This surge filter can handle short circuit currents up to a rated capacity of 25 kA while maintaining an interrupt rating of up to 100 A—safeguarding against unexpected electrical faults effectively. For ease of use during installation or maintenance tasks, tightening torques are specified as either 0.5 N-m or up to two newton meters depending on application needs.</p><p>Overall suitability extends further by being compatible with circuits rated up till thirty-two amperes thanks largely due towards having integrated fuses capped twenty amps themselves providing additional safety assurances when deployed correctly within system architectures requiring such specifications commonly found throughout Australian marketplaces today!</p>
