Stahl 225149 Visual Signalling Device Xenon Flash Tubes Lamp 24-24VDC Black Enclosure Blue Lens

Product Code: 225149

  • Durable reinforced glass fibre polyester body
  • High protection: IP66, IP67 rated
  • Operates in extreme temps: -60 to 40°C
  • ATEX & IECEx approved for safety
  • Xenon flash tubes for bright signalling
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Visual Signalling Device
Brand STAHL
Series FL6S/C
Ambient Temperature -60 to 40 deg C
Cable Cross Section 2.5 sq-mm
Cable Type Finely Stranded, Solid
Colour Black Enclosure, Blue Lens
Connection Type Screw terminal
Degree of Protection IP66, IP67
Height 287.5 mm
Lamp Type Xenon Flash Tubes
Length 148 mm
Material Reinforced Glass Fibre Polyester
Rated Voltage 24-24 VDC
Standards and Approvals ATEX (BAS), IECEx (BAS)
Width 178.5 mm

Description

<p>When choosing a signalling device for industrial or commercial applications, it&amp;#39;s essential to consider durability, compliance with safety standards, and suitability for environmental conditions. This particular signalling device is engineered to meet these demands effectively.</p><p>Constructed from reinforced glass fibre polyester, the enclosure offers robust protection against harsh environments. The black enclosure is complemented by a blue lens, providing clear visibility while maintaining an aesthetic appeal suitable for various settings. </p><p>The device&amp;#39;s resilience is further highlighted by its IP66 and IP67 ratings, ensuring it remains dust-tight and protected against powerful water jets and temporary immersion in water. This makes it well-suited for both indoor and outdoor applications where exposure to elements is a concern.</p><p>Operating efficiently within an ambient temperature range of -60 to 40 degrees Celsius, this signalling device can withstand extreme cold as well as moderate heat. Such versatility ensures reliable performance across diverse climates found in Australia.</p><p>Electrical specifications include a rated voltage of 24-24 VDC, making it compatible with standard power supplies used in many industrial setups. The cable type accommodates finely stranded or solid wires with a cross-section of up to 2.5 sq-mm, allowing flexibility during installation.</p><p>A standout feature is the use of xenon flash tubes as the lamp type. Known for their intense brightness and energy efficiency, these lamps ensure that signals are unmistakable even from considerable distances or under challenging lighting conditions.</p><p>Compliance with ATEX (BAS) and IECEx (BAS) standards underscores the product&amp;#39;s adherence to international safety requirements for explosive atmospheres—a critical factor when considering equipment for hazardous locations.</p><p>Measuring 178.5 mm in width, 287.5 mm in height, and 148 mm in length, the compact design facilitates easy integration into existing systems without demanding excessive space.</p><p>In summary, this signalling device combines robust construction materials with advanced technical features while adhering to stringent safety standards—making it an excellent choice for professionals seeking reliable alert solutions in demanding environments.</p>
