Products

Ethernet Switches

RED LION UNMANAGED ETHERNET SWITCH SL-5ES-3ST

Product Code: SL-5ES-3ST

Optimize your industrial network performance with the Red Lion NT24K Series 11-Port Gigabit Managed Ethernet Switch. Designed for robust and high-speed connectivity, this switch features eight RJ-45 ports supporting 10/100/1000BaseT and three SC duplex fiber ports for 1000BaseFX connections. It's equipped with singlemode fiber capability extending up to 80km, ensuring long-distance data transmission without compromise. Precision Time Protocol (PTP) is enabled for synchronized communication across the network. The switch operates efficiently with a power input range of 10-49 VDC and a maximum input current of 780 mA at 24 VDC. Ideal for engineers seeking reliable network solutions in demanding environments, the NT24K series offers durability and precision control in one package.

Technical Specifications

DIN Rail Width (mm) 35
Maximum Temperature (°C) 85
Minimum Temperature (°C) -40
No. of 100Mb Ports 1
No. of Ethernet Ports 4
Rated Maximum Operational Voltage DC (V) 49
Rated Minimum Operational Voltage DC (V) 10
Brand RED LION
Degree of Protection IP20
Dimensions (mm) 114H x 76W x 94D
Mounting Type DIN Rail
No. of Ports 4 x RJ45, 1 x sm Fiber ST
Operational Temperature Range (°C) -40 to +60
Rated Operational Voltage DC (V) 10 - 30
Rated Power (W) 3
Series NT24K
Standards and Approvals ATEX/IECeX
Switch Type Switch - Unmanaged
