Schmersal 101058828 Medium-Duty Position Switch Roller Plunger NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101058828

  • Rated for 400 VAC, 4 A
  • Durable grey cast iron housing
  • IP65 protection rating
  • Complies with ENIEC 60947-5-1 standards
  • Roller plunger actuator type
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Medium-Duty Position Switch
Brand SCHMERSAL
Actuating Element Roller Plunger
Actuating Speed 1 mm/min
Actuator Type Roller Plunger
Cable Cross Section 1.5 sq-mm
Contact Configuration NC
Contact Material Silver
Contact Opening (2) 6 mm
Degree of Protection IP65
Enclosure Coating Material Painted
Fuse Rating 16 A gG D-Fuse
Housing Material Grey Cast Iron, Galvanized
Mechanical Life 10000000 Operations
Rated Current 4 A
Rated Voltage 400 VAC
Standards and Approvals ENIEC 60947-5-1
Switching Type Slow Action

Description

<p>When selecting a component for industrial applications, understanding its technical specifications is crucial. This product stands out due to its robust build and reliable performance characteristics, making it suitable for demanding environments.</p><p>Operating at a rated voltage of 400 VAC and a current capacity of 4 A, this device integrates seamlessly into various electrical systems. Its construction from grey cast iron with galvanization ensures durability and resistance to harsh conditions, while maintaining the integrity required for long-term use.</p><p>The device boasts an IP65 degree of protection, which means it is dust-tight and protected against water jets from any direction. Such protection level makes it ideal for both indoor and outdoor installations where exposure to elements might be a concern.</p><p>Adhering to EN IEC 60947-5-1 standards, this product meets international benchmarks for switchgear equipment. This compliance guarantees reliability and safety in operation, which is paramount in industrial settings.</p><p>Featuring a normally closed (NC) contact configuration with slow action switching type, the product provides precise control over circuit operations. The roller plunger actuator type allows smooth mechanical interaction with moving parts in machinery or automated processes.</p><p>With an actuating speed as low as 1 mm/minute, the device offers high sensitivity to motion changes. This feature can be particularly beneficial in applications requiring precise monitoring of positional changes or movement detection.</p><p>The contacts are made from silver, ensuring excellent conductivity and longevity even under frequent operational cycles. Rated for up to 10 million mechanical operations, this product promises extended service life without compromising on performance quality.</p><p>For safety considerations during overload conditions, the fuse rating stands at 16 A gG D-Fuse. Additionally, the cable cross-section specification of 1.5 sq-mm facilitates appropriate wiring connections without risk of overheating or inefficiency.</p><p>Contact openings measure two slots of 6 mm each providing adequate spacing for secure connectivity within your systems architecture.</p><p>In summary this product combines robust material construction stringent compliance with industry standards superior contact materials and thoughtful design features catering specifically towards professionals seeking reliable components that perform consistently under challenging conditions providing peace-of-mind through dependable engineering solutions tailored towards enhancing operational efficiency across diverse industrial landscapes</p>
