Schmersal 101059075 Medium-Duty Position Switch Offset Roller Lever NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101059075

  • Rated for 400 VAC and 4 A
  • Durable grey cast iron housing
  • IP65 protection against dust and water
  • Complies with ENIEC 60947-5-1 standards
  • Offset roller lever actuator
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Medium-Duty Position Switch
Brand SCHMERSAL
Actuating Element Offset Roller Lever
Actuating Speed 1 mm/min
Actuator Type Offset Roller Lever
Cable Cross Section 1.5 sq-mm
Contact Configuration NC
Contact Material Silver
Contact Opening (2) 6 mm
Degree of Protection IP65
Enclosure Coating Material Painted
Fuse Rating 16 A gG D-Fuse
Housing Material Grey Cast Iron, Galvanized
Mechanical Life 10000000 Operations
Rated Current 4 A
Rated Voltage 400 VAC
Standards and Approvals ENIEC 60947-5-1
Switching Type Slow Action

Description

<p>When it comes to industrial automation, having reliable components is crucial for ensuring seamless operations. This product, designed to meet the rigorous demands of industrial and commercial environments, offers a blend of durability and precision.</p><p>Operating at a rated voltage of 400 VAC with a current rating of 4 A, this device is well-suited for various applications requiring consistent power delivery. The housing material made from grey cast iron with galvanization ensures robustness and longevity, making it ideal for harsh conditions.</p><p>The degree of protection rated at IP65 guarantees that the product is dust-tight and protected against water jets from any direction. This makes it particularly suitable for environments where exposure to moisture or particles is common. Compliance with EN/IEC 60947-5-1 standards further underscores its reliability in safety-critical applications.</p><p>Featuring an offset roller lever as its actuator type, the device employs a slow-action switching mechanism. This configuration includes normally closed (NC) contacts crafted from silver, which provides excellent conductivity and resistance to wear over time. With an actuating speed set at 1 mm/min, it&amp;#39;s designed for precise control in automated systems.</p><p>For additional safety measures, the fuse rating stands at 16 A gG D-Fuse, ensuring protection against overcurrents without compromising performance. The contact opening size is specified as two separate openings measuring 6 mm each—a detail critical during installation or maintenance procedures.</p><p>In terms of connectivity, the cable cross-section accommodates up to 1.5 sq-mm wires—providing flexibility in integrating with existing systems or new installations alike. Furthermore, its mechanical life spans up to an impressive ten million operations—highlighting its capability to endure extensive use without frequent replacements.</p><p>Overall, this product embodies reliability through meticulous engineering tailored for demanding scenarios found within industrial settings—from manufacturing plants to large-scale commercial facilities—where dependability cannot be compromised under any circumstance.</p>
