Schmersal 101059468 Medium-Duty Position Switch Roller Lever 1NO Grey Cast Iron Galvanized Silver Contact

Product Code: 101059468

  • Rated for 400 VAC and 4 A
  • Durable grey cast iron housing
  • IP65 protection against dust and water
  • Complies with ENIEC 60947-5-1 standards
  • Roller lever actuator with slow action
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Medium-Duty Position Switch
Brand SCHMERSAL
Actuating Element Roller Lever
Actuating Speed 1 mm/min
Actuator Type Roller Lever
Cable Cross Section 1.5 sq-mm
Contact Configuration 1NO
Contact Material Silver
Contact Opening (2) 6 mm
Degree of Protection IP65
Enclosure Coating Material Painted
Fuse Rating 16 A gG D-Fuse
Housing Material Grey Cast Iron, Galvanized
Mechanical Life 10000000 Operations
Rated Current 4 A
Rated Voltage 400 VAC
Standards and Approvals ENIEC 60947-5-1
Switching Type Slow Action

Description

<p>When selecting an industrial switch for your operation, reliability and adherence to standards are key. This particular model offers a robust solution, crafted with precision to meet demanding environments.</p><p>Designed for efficiency, the switch operates at a rated voltage of 400 VAC and supports a current rating of 4 A. It features a slow-action switching type with a roller lever actuator, ensuring smooth operations even in high-demand settings. The contact configuration is 1NO (normally open), which can be advantageous in applications where you need the circuit closed only when the switch is actuated.</p><p>Built from grey cast iron and galvanized materials, this product promises durability and resilience against harsh conditions. Its IP65 degree of protection guarantees that it is dust-tight and protected against water jets, making it suitable for both indoor and outdoor installations.</p><p>The switch complies with EN IEC 60947-5-1 standards, offering peace of mind that it meets international safety guidelines. With silver contacts known for excellent conductivity and resistance to corrosion, this device ensures reliable electrical performance over time.</p><p>For those concerned about longevity, this switch boasts an impressive mechanical life of up to 10 million operations. This makes it ideal for applications where frequent actuation is required without compromising on performance or lifespan.</p><p>Additionally, the fuse rating stands at 16 A gG D-Fuse, providing ample protection against potential overcurrent scenarios. The cable cross-section accommodates up to 1.5 sq-mm wires, allowing flexibility in installation setups.</p><p>With an actuating speed as precise as 1 mm/min and contact openings measuring two slots at 6 mm each, this product delivers meticulous control tailored to your operational needs.</p><p>In summary, if you&amp;#39;re seeking a dependable switch that combines rugged construction with precise engineering standards compliance — all while maintaining ease of integration into existing systems — this model should be on your shortlist.</p>
