Schmersal 101059446 Medium-Duty Position Switch Roller Lever 1NO-1NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101059446

  • Rated for 230 VAC, 4 A
  • Durable grey cast iron housing
  • IP65 protection against dust and water
  • Snap action with roller lever actuator
  • Compliant with ENIEC 60947-5-1 standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Medium-Duty Position Switch
Brand SCHMERSAL
Actuating Element Roller Lever
Actuating Speed 1 mm/min
Actuator Type Roller Lever
Cable Cross Section 1.5 sq-mm
Contact Configuration 1NO+1NC
Contact Material Silver
Contact Opening (2) 2.5 mm
Degree of Protection IP65
Enclosure Coating Material Painted
Fuse Rating 16 A gG D-Fuse
Housing Material Grey Cast Iron, Galvanized
Mechanical Life 5000000 Operations
Rated Current 4 A
Rated Voltage 230 VAC
Standards and Approvals ENIEC 60947-5-1
Switching Type Snap Action

Description

<p>When it comes to selecting a reliable and robust switch for industrial and commercial applications, this product stands out as a well-engineered choice. Designed with precision, it caters to the demanding needs of technical professionals who prioritize performance and durability.</p><p>Operating at a rated voltage of 230 VAC with a current capacity of 4 A, this switch is built to handle moderate electrical loads efficiently. Its construction from grey cast iron and galvanized materials ensures exceptional durability and resistance to environmental factors, making it suitable for various industrial settings.</p><p>The IP65 degree of protection signifies that the switch is dust-tight and protected against water jets, which enhances its reliability in challenging environments. Compliance with the ENIEC 60947-5-1 standards further guarantees adherence to international safety and performance norms.</p><p>Featuring a contact configuration of 1NO+1NC (one normally open and one normally closed), this device offers versatile switching capabilities. The snap action switching type ensures rapid response times, crucial for applications requiring quick actuation. The roller lever actuator type provides smooth operation with an actuating speed as low as 1 mm/min—ideal for precision tasks.</p><p>Constructed using silver contact material, the switch promises excellent conductivity and longevity. It supports a fuse rating of 16 A gG D-Fuse, providing an additional layer of protection against overcurrent scenarios.</p><p>The cable cross-section accommodates up to 1.5 sq-mm wires, allowing for adequate electrical connectivity without compromising on safety or efficiency. Notably, the contact opening measures (2) 2.5 mm, ensuring consistent performance over its mechanical life span of five million operations—a testament to its robust design aimed at long-term use.</p><p>In summary, this switch combines practicality with resilience through thoughtful engineering choices such as high-grade materials, compliance with stringent standards like ENIEC 60947-5-1, and features designed for ease-of-use in diverse environments. Whether used in automation systems or other industrial applications requiring dependable switches—this product delivers on both fronts: reliability and functionality.</p>
