Schmersal 101058560 Medium-Duty Position Switch Plunger 1NO-1NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101058560

  • Rated for 250 VAC and 4 A
  • Durable grey cast iron housing
  • IP65 protection against dust and water
  • Complies with ENIEC 60947-5-1 standards
  • Snap action plunger actuator
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Medium-Duty Position Switch
Brand SCHMERSAL
Actuating Element Plunger
Actuating Speed 1 mm/min
Actuator Type Plunger
Cable Cross Section 1.5 sq-mm
Contact Configuration 1NO+1NC
Contact Material Silver
Contact Opening (2) 2.5 mm
Degree of Protection IP65
Enclosure Coating Material Painted
Fuse Rating 16 A gG D-Fuse
Housing Material Grey Cast Iron, Galvanized
Mechanical Life 5000000 Operations
Rated Current 4 A
Rated Voltage 250 VAC
Standards and Approvals ENIEC 60947-5-1
Switching Type Snap Action

Description

<p>When selecting a switch for industrial or commercial applications, the focus is on durability, reliability, and compliance with standards. This product is designed to meet these needs with precision.</p><p>Operating at a rated voltage of 250 VAC and a current capacity of 4 A, this switch is suitable for various electrical systems. Its housing, crafted from grey cast iron and galvanized material, ensures robust protection against environmental factors. With an IP65 degree of protection, it offers excellent resistance to dust ingress and water jets from any direction—ideal for demanding conditions where exposure to elements is frequent.</p><p>The switch complies with ENIEC 60947-5-1 standards and approvals, ensuring safety and performance in line with international benchmarks. The contact configuration features one normally open (NO) and one normally closed (NC) contact, providing flexibility for different circuit requirements. Utilizing snap action switching type technology allows rapid transition between states, which can be crucial in high-speed operations.</p><p>Equipped with a plunger actuator type mechanism, this switch requires an actuating speed of just 1 mm/min—a feature that supports precise control in automated environments. The contact material made from silver enhances conductivity while minimizing wear over time.</p><p>For added safety measures during operation overloads or short circuits, the fuse rating stands at 16 A gG D-Fuse. This specification helps protect connected components by interrupting excessive currents effectively.</p><p>The cable cross-section accommodates up to 1.5 sq-mm wires efficiently without compromising connectivity quality or integrity under stress conditions common in industrial setups. Contact openings measure (2) 2.5 mm each—allowing ample space for secure wiring connections.</p><p>With an impressive mechanical life expectancy reaching up to five million operations before maintenance might be necessary; longevity becomes less concerning even under intensive usage scenarios across diverse industries such as manufacturing plants or commercial facilities requiring reliable automation solutions daily.</p><p>In summary: built tough yet versatile enough thanks largely due its comprehensive set specifications meeting rigorous demands head-on while maintaining adherence globally recognized criteria throughout service lifespan unmatched value proposition presented here makes it worthy consideration those seeking dependable component integration into their systems seamlessly!</p>
