Schmersal 101058315 Slack Wire Switch 1NO-1NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101058315

  • Rated for 230 VAC, 4 A current
  • Durable grey cast iron housing
  • IP65 protection against dust & water
  • Complies with ENIEC 60947-5-1 standards
  • Snap action switch with silver contacts
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Slack Wire Switch
Brand SCHMERSAL
Cable Cross Section 1.5 sq-mm
Contact Configuration 1NO+1NC
Contact Material Silver
Contact Opening (2) 2.5 mm
Degree of Protection IP65
Enclosure Coating Material Painted
Fuse Rating 16 A gG D-Fuse
Housing Material Grey Cast Iron, Galvanized
Mechanical Life 10000000 Operations
Rated Current 4 A
Rated Voltage 230 VAC
Standards and Approvals ENIEC 60947-5-1
Switching Type Snap Action

Description

<p>When selecting components for industrial or commercial applications, reliability and compliance with standards are crucial. This product, constructed with durability in mind, is designed to meet the rigorous demands of various technical environments.</p><p>With a rated voltage of 230 VAC and a current capacity of 4 A, this device ensures efficient performance across numerous applications. The housing is crafted from grey cast iron and galvanized materials, offering robust protection against wear and tear while maintaining a sleek appearance. Its IP65 rating signifies excellent resistance to dust ingress and water jets from any direction, making it suitable for challenging environments where exposure to the elements is a concern.</p><p>Adhering to EN IEC 60947-5-1 standards, this product assures users that it meets stringent international quality and safety criteria. The contact configuration consists of one normally open (NO) and one normally closed (NC) contact, providing versatile switching options for various circuit designs. The snap action switching type ensures quick response times, which can be critical in automation processes.</p><p>The contacts are made from silver material known for its excellent conductivity properties which reduce resistance losses during operation. For added safety measures, the fuse rating stands at 16 A gG D-Fuse ensuring protection against overcurrent situations without compromising on performance.</p><p>Accommodating a cable cross-section of up to 1.5 sq-mm allows for sufficient electrical flow without overheating issues while maintaining flexibility in wiring setups. The contact opening features two openings each measuring 2.5 mm which facilitates easy connection or disconnection during maintenance tasks or system upgrades.</p><p>This product boasts an impressive mechanical life expectancy with up to ten million operations underscoring its suitability for long-term use in high-demand settings reducing downtime associated with frequent replacements or repairs.</p><p>In summary this component combines rugged construction reliable operation and adherence to international standards making it an ideal choice for professionals seeking dependable solutions in their projects whether they involve automation systems building infrastructures or other technical installations demanding consistent performance over time while minimizing maintenance efforts involved thus maximizing efficiency throughout its service life</p>
