SCHMERSAL LIGHT TERMINAL BLOCK 250 V LED GREEN 101166023

Product Code: 101166023

Light Terminal Block with a rated operating voltage of 250V. The LED is green in colour and the enclosure material is made of plastic, specifically glass-fiber reinforced thermoplastic which is self-extinguishing. The screw terminals are M20 x 1.5 and pluggable. The dimensions of the terminal block are 46mm in length, 30mm in width, and 60mm in depth. It has a degree of protection for clips or terminals of IP20.

Technical Specifications

Pluggable Yes
Brand SCHMERSAL
Ambient Temperature Range (°C) -25 to 80
Degree of Protection IP20
Dimensions (mm) 46L x 30W x 60D
Housing Material Thermoplastic
LED Colour Green
Rated Operational Voltage (V) 250
Standards and Approvals EN IEC 60947-1, EN IEC 62061, EN IEC 60947-5-1/-5-3/-5-5, EN IEC 60204-1, cULus, CCC, EAC
Terminal Type Screw (M20 x 1.5)
