SCHMERSAL BNS36-11Z-R SAFETY SENSOR 101193120

Product Code: 101193120

Enhance machine safety with the Schmersal BNS36 series safety sensor, designed for reliability and durability. This thermoplastic-encased sensor features a magnetic actuating element and is suitable for right-hinged doors. It includes one opener and one shutter, along with two safety contacts to ensure secure operations. The unit is equipped with four cable wires and a 1-meter long cable for easy installation. With a switching voltage of 75 VDC, current of 0.4 A, and capacity of 10 W, this sensor maintains efficient performance in various industrial applications. Trust in the Schmersal brand for your machine safety needs with this robust safety sensor solution.

Technical Specifications

Brand SCHMERSAL
Maximum Temperature (°C) 70
Minimum Temperature (°C) -25
Nominal Output Current (A) 0.4
Nominal Power (W) 10
Rated Maximum Operational Voltage DC (V) 75
Degree of Protection IP67
Series BNS36
