Brand	SCHMERSAL
Actuating Element	Magnet
Direction of Motion	Head-on to the Active Surface
Installation Conditions	Not Flush
Maximum Storage Temperature (°C)	70
Maximum Switching Capacity (W)	10
Maximum Switching Frequency (Hz)	5
Maximum Switching Voltage DC (V)	100
Minimum Ambient Temperature (°C)	-25
Minimum Storage Temperature (°C)	-25
Recommended Actuator	BPS 16
Recommended Safety Switchgear	SRB-E-301ST
Resistance to Shock (g/ms)	30g / 11ms
Resistance to Vibrations	10 ... 55Hz, Amplitude 1mm
Sensor Height (mm)	90
Sensor Length (mm)	39
Sensor Width (mm)	52
Termination	Connector M12
Degree of Protection	IP67
Housing Material	Glass-fibre, Reinforced Thermoplastic
Maximum Ambient Temperature (°C)	70
Maximum Switching Current (A)	0.4
Maximum Switching Voltage AC (V)	100
No. of Normally-closed Contacts	1
No. of Normally-open Contacts	1
Standards and Approvals	EN IEC 60947-5-3, EN ISO 13849-1

Presence Sensing Safety Devices

SCHMERSAL BNS 16-11ZV-ST1MAGNETIC SAFETY SENSOR 101192588
