Schmersal 101164015 Safety Switch with Separate Actuator 1NO+1NC

Product Code: 101164015

  • Rated current of 1000 A
  • Durable with 1 million cycles
  • IP67 protection rating
  • Operates from -30 to 80°C
  • Meets EN IEC & ISO standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Safety Switch with Separate Actuator
Brand SCHMERSAL
Action Slow Action, Positive Break NC Contact
Actuating Speed 2 m/s
Cable Entry 3 x M16 x 1.5
Contact Configuration 1NO+1NC
Contact Material Silver
Degree of Protection IP67
Housing Material Plastic, Glass Fibre Reinforced Thermoplastic
Mechanical Life 1000000 Cycles
Operational Temperature -30 to 80 deg C
Rated Current 1000 A
Rated Frequency 4000/h
Rated Insulation Voltage 500 V
Sensor Size 30 mm L x 52 mm W x 90 mm H
Standards and Approvals EN IEC 60947-5-1, EN ISO 13849-1

Description

<p>For professionals in the electrical engineering and automation sectors, selecting the right components is crucial to ensure both safety and efficiency. This product stands out with its robust specifications tailored for demanding industrial applications.</p><p>The device operates at a rated current of 1000 A, making it suitable for high-power applications. Its rated frequency of 4000 operations per hour ensures reliability in fast-paced environments where frequent switching is required. The contact configuration includes one normally open (1NO) and one normally closed (1NC) contact, allowing versatile integration into various control systems.</p><p>Durability is a key feature here, with an impressive mechanical life of one million cycles. This longevity reduces maintenance costs and downtime, ensuring consistent performance over time. The housing material comprises plastic reinforced with glass fibre thermoplastic, providing strength and durability while maintaining a lightweight profile.</p><p>With an IP67 degree of protection, this product offers excellent resistance against dust ingress and temporary immersion in water—ideal for harsh industrial settings. It operates efficiently across a wide temperature range from -30 to 80 degrees Celsius, making it suitable for diverse environmental conditions.</p><p>The product complies with EN IEC 60947-5-1 and EN ISO 13849-1 standards, underscoring its quality and safety credentials. These certifications assure users that the device meets rigorous international benchmarks for performance and reliability.</p><p>In terms of functionality, it features slow action with a positive break NC contact design—a critical aspect that enhances safety by ensuring contacts are mechanically forced apart during operation. An actuating speed of 2 meters per second allows for responsive operation without compromising on precision or control.</p><p>Measuring at 30 mm in length, 52 mm in width, and 90 mm in height, this sensor&amp;#39;s compact size facilitates easy installation even in space-constrained areas. The contacts are made from silver to provide excellent conductivity and resistance to corrosion over time.</p><p>Rated insulation voltage stands at 500 V which provides ample headroom for most industrial applications requiring reliable insulation properties under varying load conditions.</p><p>Overall, this product delivers on multiple fronts: durability through extensive lifecycle capabilities; versatility via adaptable contact configurations; protection assured by stringent adherence to international standards; all wrapped up within a robust yet compact form factor suited perfectly towards meeting your technical requirements seamlessly within any demanding operational environment you might encounter.</p>

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
