Safety Pushbuttons & Operator Devices

IDEC SAFETY SWITCH METAL HEAD 1NO-2NC HS5D-12ZRNM

Product Code: HS5D-12ZRNM

The IDEC HS5D-12ZRNM Safety Switch features a robust metal head and offers enhanced safety through its head detachment detection capability. It includes 2NC contacts and allows for easy wiring, ensuring quick installation. The switch's compact design accommodates up to three contacts and is equipped with an M20 gland port size for secure cable management. With a high B10d value of 2.0E+16, it promises reliable performance in demanding industrial environments.

Technical Specifications

Resistance to Shock (m/s²) 1000
Resistance to Vibrations 10 to 55Hz
Brand IDEC
Degree of Protection IP67
Minimum Electrical Life 100000
Minimum Mechanical Life 1000000
No. of Normally-closed Contacts 2
No. of Normally-open Contacts 1
Operating Humidity 45 to 85%
Operational Temperature Range (°C) -30 to 70
Rated Insulation Voltage (V) 300
Rated Thermal Current - Ith (A) 10
Weight (g) 80g - Plastic Head, 110g - Metal Head
