IDEC RELAY SLIM LINE SPDT 24VDC 12A RJ1S-CL-D24

Product Code: RJ1S-CL-D24

The IDEC RJ1S-CL-D24 is a Slim Line Power Relay designed for efficient single pole applications. It features an SPDT configuration and operates with a 24VDC coil voltage, handling a switching current of up to 12A. The relay boasts a compact 12.7mm housing with a non-polarized LED indicator and is known for its excellent electrical and mechanical longevity. Ideal for engineers looking for reliable and space-saving power relays.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 24
Contact Configuration SPDT
Contact Material Silver-nickel alloy
Degree of Protection IP40
Dielectrical Strength (kV) Between Contact and Coil: 5, Between Contacts of the Same Pole: 1
No. of Poles 1P
Operational Temperature Range (°C) -40 to +70
Rated Current (A) 12
Relay Type RJ1S 1PDT Relay with LED indicator
Series RJ
Suitable Base SJ1S-07LW
Terminal Type Plug-in
Weight (g) 19
