Product Code: RU2S-D-D24

The IDEC RU2S-D-D24 is a compact, full-featured DPDT plug-in relay designed for versatile applications. It features a 10A contact rating and operates on a 24VDC power supply with an integrated diode and latching lever for stability. The relay boasts an environmentally friendly design with no internal wires and lead-free construction. A non-polarized LED indicator and mechanical flag provide visual status, while the snap-on yellow marking plate facilitates easy identification.

Brand	IDEC
Coil Voltage DC (V)	24
Contact Configuration	DPDT
Contact Material	Silver alloy
Dielectrical Strength (kV)	Between contact and coil: 2.5
Insulation Resistance (MO)	100
Model	With diode (DC coil only)
No. of Poles	2P
Operating Humidity	5 to 85% RH (no condensation)
Operational Temperature Range (°C)	–55 to +60
Rated Continuous Current (A)	10
Rated Current (A)	10
Relay Type	RU2 2PDT Relay with LED indicator
Series	RU
Storage Temperature (°C)	-55 to +70
Storage Temperature Range (°C)	–55 to +70
Suitable Base	SM2S-05C
Terminal Type	Plug-in
Weight (g)	35
Weight (kg)	0.035
