IDEC RELAY DPDT 12V DC 3A WITH INDICATOR RY2S-ULDC12V

Product Code: RY2S-ULDC12V

The IDEC RY2S-ULDC12V is a compact, industrial general-purpose signaling relay designed for efficient operation. It features a DPDT (Double Pole Double Throw) configuration that allows for versatile switching applications. With a contact rating of 3A and 12V DC coil voltage, this relay is suitable for a wide range of uses. Additionally, it meets RoHS compliance standards, ensuring environmentally safe usage.

Technical Specifications

Brand IDEC
Contact Resistance (mO) 50
Power Consumption (VA) AC: 1.1VA (50Hz), 1VA (60Hz)
Relay Options Indicator Light
Resistance to Shock (m/s²) 100
Resistance to Vibrations 10 to 55Hz
Ambient Temperature Range (°C) -25 to 50
Coil Voltage DC (V) 12
Contact Configuration DPDT
Contact Material Gold-plated Silver
Contacts DPDT
Dimensions (mm) 14W x 35.6H x 27.5D
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 Operations
Minimum Mechanical Life 50,000,000 Operations
Model With Indicator
Operational Temperature Range (°C) -25 to 50
Power Consumption (W) DC: 0.8W
Rated Current (A) 3
Terminal Type Blade
Weight (g) 23
