Red Lion C48CS104 Single Preset Counter 85-250VAC 6 Digit Backlit LCD Display

Product Code: C48CS104

  • Operates on 85-250 VAC with 12 VDC sensor power
  • Compact panel mount design, 49.5 mm square face
  • Backlit LCD display with 6 digits for easy reading
  • IP65 rated for protection against dust and water
  • Complies with EN and UL standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Single Preset Counter
Brand RED LION
Degree of Pollution IP2
Degree of Protection IP65
Depth 105.9 mm
Display Size 0.3 in, 0.2 in
Display Type Backlit LCD
Height 49.5 mm
Humidity 85%
Mounting Type Panel
Number of Display Digits 6
Operational Temperature 0 to 50 deg C
Output Type Relay & Solid State
Rated Voltage 85-250 VAC
Sensor Power 12 VDC
Standards and Approvals EN 61010-1, EN 61010-2-030, EN 61326-1, RoHS, UL Recognized
Weight 0.17 kg
Width 49.5 mm

Description

<p>When selecting a reliable counter for industrial and commercial applications, technical accuracy and robust performance are essential. This mid-lifecycle product is designed to meet those demands with precision and efficiency.</p><p>This counter operates on a rated voltage of 85-250 VAC, ensuring compatibility with various power sources. Its backlit LCD display provides clear visibility in diverse lighting conditions, featuring six digits for comprehensive data representation. The display sizes of 0.3 inches and 0.2 inches cater to different viewing preferences while maintaining readability.</p><p>A key attribute is its sensor power capability at 12 VDC, which supports seamless integration with existing systems. Designed for panel mounting, it fits neatly into control panels with dimensions of 49.5 mm in width and height, complemented by a depth of 105.9 mm for streamlined installation.</p><p>Durability is assured with an IP65 degree of protection, safeguarding against dust ingress and low-pressure water jets from any direction—ideal for challenging environments where reliability is non-negotiable. The counter&amp;#39;s operational temperature range from 0 to 50 degrees Celsius allows it to perform consistently across varying climates.</p><p>The unit adheres to high safety standards including EN 61010-1, EN 61010-2-030, EN 61326-1 along with RoHS compliance and UL recognition—providing assurance that the device meets rigorous international quality benchmarks.</p><p>Weighing just 0.17 kg, this counter&amp;#39;s lightweight design does not compromise its durability or functionality—a testament to efficient engineering tailored for demanding settings.</p><p>Whether you&amp;#39;re upgrading current systems or integrating new solutions into your operations, this counter offers the dependable performance you need without unnecessary complexity or excess features that don&amp;#39;t add value in practical applications.</p><p>In summary, this product presents a harmonious balance between technical sophistication and user-friendly operation—an ideal choice for professionals seeking a reliable solution that delivers on all fronts without fuss or fanfare.</p>
