IDEC PLUG-IN TIMER 8 PIN 12VDC SPDT GT3A-2D12

Product Code: GT3A-2D12

The Plug-in Multifunction Timer offers 4 selectable operation modes on each model. It features external start, reset, and pause inputs on 11 pin models. The timer is designed with a standard 8 pin base and includes power and output status indicating LEDs. It has a time range of 0.05s to 180H and operates at a rated input voltage of 12VDC. The timer supports Delayed SPDT + Instantaneous SPDT mode of operation, with options for ON-Delay 1, Interval 1, Cycle 1, and Cycle 3.

Technical Specifications

Brand IDEC
Series GT3A
Operational Temperature Range (°C) -10 to +50
Storage Temperature (°C) -30 - +70
Contacts Delayed SPDT + Instantaneous SPDT
Input Voltage AC (V) 100 - 240
Input Voltage AC/DC (V) 24
Input Voltage DC (V) 12
Insulation Resistance (MO) 100
No. of Pins 8
Output Voltage AC (V) 24
Output Voltage DC (V) 12
Timing Range 0.1s - 180hrs
Degree of Protection IP40 (Timer), IP20 (Socket)
Pollution Degree 2
Standards and Approvals EN 61812-1:2011, EN IEC 63000:2018
