IDEC YW1P-1BUQM3A PILOT LIGHT WITH LED AMBER 230/240VAC FLUSH 22MM UNIBODY

Product Code: YW1P-1BUQM3A

The IDEC YW1P-1BUQM3A Unibody Pilot Light is a streamlined lighting device featuring an integrated LED that produces an amber glow. Designed for 230/240VAC systems, it offers flush mounting with a 22mm hole. The pilot light ensures user safety with IP20 finger safe terminals, making it suitable for engineering applications where compact and reliable indication lights are essential.

Technical Specifications

Brand IDEC
Degree of Protection IP65 (Front), IP20 (Terminals)
Insulation Resistance (MO) 100
Lamp Type Built-in LED
LED Colour Amber
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC (V) 230/240
Series YW
Terminal Type Screw (M3.5)
