IDEC YW1P-1BUQ3A PILOT LIGHT WITH LED AMBER 12VAC/DC FLUSH 22MM UNIBODY

Product Code: YW1P-1BUQ3A

The IDEC YW1P-1BUQ3A Unibody Pilot Light is a versatile signaling device with an integrated amber LED for clear visibility. It operates on both 12VAC and 12VDC, allowing for flexible installation options. Designed with a flush profile and a standard 22mm mounting size, it easily fits into control panels. The pilot light's IP20 rating guarantees protection against finger contact.

Technical Specifications

Brand IDEC
Degree of Protection IP65 (Front), IP20 (Terminals)
Insulation Resistance (MO) 100
Lamp Type Built-in LED
LED Colour Amber
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC/DC (V) 12
Series YW
Terminal Type Screw (M3.5)
