Photovoltaic Isolators & Protection

ADLER FUSE LINK 80A 1300V DC 22X58mm FERRULE TYPE A942800B00

Product Code: A942800B00

The A94 Photovoltaic (PV) fuse link is a high-power solution for PV applications. It has a 22x58 mm size and features a glass-fiber body. With a gPV rating of 1300 VDC, it is designed to handle the demands of photovoltaic systems. The fuse link also comes with silver plated caps for enhanced performance.

Technical Specifications

Brand ADLER
Diameter (mm) 22
Interrupting Rating (kA) 10
Length (mm) 58
Pack Quantity 20
Power Loss (W) 12
Rated Current (A) 80
Rated Voltage DC (V) 1300
Suitable Fuse Holder BH400
Terminal Type Ferrule
Time Constant (ms) 1-3
