Novaris SSP3-63-100-275A Surge Protector 3-P 3 PH 63A 100kA 230VAC TS35 Panel Mount Metal IP20

Product Code: SSP3-63-100-275A

  • Protects against surges up to 100 kA
  • Quick response time of <5 ns (L-N)
  • LED status display for each phase
  • Suitable for TS35 DIN rail or panel mount
  • Complies with IEC, AS/NZS, UL standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Surge Protector
Brand NOVARIS
Series SSP3
Connection Type Series
Degree of Protection IP20
Depth 95 mm
Discharge Current 100 kA
Display Type LED Status per Phase
Fuse Rating 63 A
Height 69 mm
Housing Material Metal
Humidity 5-95%
Interrupt Rating 100 A
Material Metal
Modes of Protection L-N, L-PE, N-PE
Mounting Type TS35 DIN Rail, Panel
Number of Poles 3
Operational Temperature -40 to 70 deg C
Phase 3
Rated Current 63 A
Rated Short Circuit Current 25 kA
Rated Voltage 230 VAC
Response Time <5 ns (L-N), <100 ns (N-PE)
Standards and Approvals IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002
Voltage Protection Level <800 V
Weight 750 g
Width 126 mm

Description

<p>When it comes to safeguarding your industrial or commercial electrical systems, the right surge protection device (SPD) can make all the difference. This SPD is engineered to provide robust protection against voltage spikes, ensuring that your equipment remains safe and operational even in adverse conditions.</p><p>Operating at a rated voltage of 230 VAC with a current rating of 63 A, this SPD is designed for three-phase systems. It features an LED status display for each phase, allowing for quick and easy monitoring of its operational state. The device&amp;#39;s compact dimensions—126 mm in width, 69 mm in height, and 95 mm in depth—make it suitable for installations where space is limited.</p><p>The SPD is built from durable metal and offers a degree of protection rated at IP20. This makes it ideal for indoor applications where exposure to dust or moisture is minimal. It&amp;#39;s versatile when it comes to mounting options as well, supporting both TS35 DIN rail and panel installations.</p><p>In terms of performance standards, this SPD complies with several key industry benchmarks: IEC 61643-11:2011 ensures reliable surge protective performance; AS/NZS 1768:2007 confirms its suitability for Australian conditions; UL 1449 3rd Edition provides assurance regarding safety; while IEEE 62.41.2:2002 covers its endurance under various power quality scenarios.</p><p>The device operates efficiently across a wide temperature range from -40&amp;#176;C to +70&amp;#176;C and can handle humidity levels between 5% and 95%. With a weight of just 750 g, it&amp;#39;s lightweight yet robust enough for demanding environments.</p><p>Its response time is impressively fast at less than five nanoseconds (L-N) and under one hundred nanoseconds (N-PE), which means it acts almost instantaneously to protect your system components from transient overvoltages. The discharge current capacity stands at an impressive 100 kA, offering substantial energy diversion capability during surges.</p><p>Protection modes include L-N (Line-Neutral), L-PE (Line-Protective Earth), and N-PE (Neutral-Protective Earth). This comprehensive coverage ensures that all potential pathways are safeguarded against surges.</p><p>With an interrupt rating of up to 100 A along with a fuse rating also set at 63 A, this device promises reliability without compromising on safety parameters. Its voltage protection level remains below the threshold of &amp;lt;800 V during operation ensuring sensitive electronics remain unharmed by excessive voltages.</p><p>Finally yet importantly important technical specification includes rated short circuit current handling capacity reaching up towards maximums around approximately twenty-five kiloamperes thus providing additional peace-of-mind knowing full well equipment investments protected adequately through such high-performance specifications designed into product itself inherently!</p>
