Product Code: SLH2-36-G

High Energy Signal Line Protector 1 pair, Maximum continuous voltage (Uc) 36VDC & 30VAC , Maximum discharge current Imax (8/20 s) 10 kA per line (20 kA common mode), Maximum impulse current Iimp (10/350 s) 2.5 kA per line (5 kA common mode), Maximum load current (IL) 2.5 A, Voltage protection level Up @ 1 kV/ s <70V (L-L) & < 400V (L-PE). Series connection, G Base (Earth connected to DIN rail). Ideal railway signaling, SCADA output signals and process controllers suit for areas of high lightning activity, failsafe design external alarm. DIN rail IP20

Maximum Load Current - I? (A)	2.5
No. of Pairs	1
Voltage Protection Level (1kV/µs) - Up (kV)	0.07 (L-L), 0.4 (L-PE)
Brand	NOVARIS
Connection Type	Series
Degree of Protection	IP20
Dimensions (mm)	110H x 12W x 71D
Lightning Impulse Current (10/350 µs) - Iimp (kA)	2.5 kA per line (5 kA common mode)
Maximum Continuous Operating Voltage MCOV AC (V)	30
Maximum Continuous Operating Voltage MCOV DC (V)	36
Maximum Discharge Current (8/20µs) - Imax (kA)	10 (per line), 20 common mode)
Mounting Type	DIN rail
Operational Temperature Range (°C)	-40 to 70
Series	SLH2
Standards and Approvals	IEC 61643-21, AS/NZS 1768, UL497, A, B, AS/NZS 4117

Lightning & Surge Protection

NOVARIS HIGH ENERGY SIGNAL LINE SURGE PROTECTOR 1 PAIR 20kA SLH2-36-G

Product Code: SLH2-36-G

Technical Specifications
