IDEC YW1B-A1E10G NON-ILLUMINATED PUSHBUTTON GREEN FLUSH MAINTAINED 1NO

Product Code: YW1B-A1E10G

The IDEC YW1B-A1E10G is a non-illuminated, green flush maintained pushbutton designed for secure and reliable operation. It features a 22mm mounting size and a finger-safe terminal for enhanced safety. The pushbutton provides IP20 protection and includes 1 normally open (NO) contact, making it suitable for various industrial applications where consistent performance is required.

Technical Specifications

Brand IDEC
Bezel Type Plastic
Colour Green
Contact Material Silver
Contacts 1NO
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Degree of Protection IP65 (Front), IP20 (Terminals)
Illumination Non-Illuminated
Insulation Resistance (MO) 100
Mode of Operation Maintained
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Series YW
Terminal Type Screw (M3.5)
