IDEC YW1B-M1E10B NON-ILLUMINATED PUSHBUTTON BLACK FLUSH MOMENTARY 1NO

Product Code: YW1B-M1E10B

The IDEC YW1B-M1E10B is a non-illuminated, black flush pushbutton designed for momentary operation with a single normally open (NO) contact. It accommodates a 22mm mounting size and offers an IP20 rating for protection against solid objects. For enhanced safety, it is equipped with finger-safe terminals. This pushbutton is suitable for applications requiring reliable and safe momentary switching.

Technical Specifications

Brand IDEC
Bezel Type Plastic
Colour Black
Contact Material Silver
Contacts 1NO
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Degree of Protection IP65 (Front), IP20 (Terminals)
Illumination Non-Illuminated
Insulation Resistance (MO) 100
Mode of Operation Momentary
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Series YW
Terminal Type Screw (M3.5)
