Evolution Distribution Boards

IPD E65LMTR48P METER ENCLOSURE IP65 GREY 1000H

Product Code: E65LMTR48P

The E65 Meter enclosure is a double hinged meter panel made from Type X Switch panel. It has an IP65 rating and comes in RAL 7035 Grey colour. The enclosure size is 1000H x 600W x 300D mm, with 110mm of space behind the panel and 180mm in front of the panel. The switch panel size is 550W x 550H mm and it features a 48P DIN configuration.

Technical Specifications

Brand IPD
Colour Grey, RAL7035
Degree of Protection IP65
Dimensions (mm) 1000H x 600W x 300D
Material Mild Steel
Switch Panel Dimensions (mm) 550H x 550W
