Product Code: 942 170-999-006

The Hirschmann BOBCAT Series Managed Industrial Switch is a robust networking solution designed for demanding industrial environments. This Fast Ethernet switch features 12 ports, including 8 RJ45 ports supporting 10/100BASE TX and 4 fiber ports with dual-speed capabilities of 100/1000Mbit/s. It offers high flexibility with four Gigabit SFP slots for uplink connections, ensuring efficient data flow and network scalability. Engineered for reliability, it operates within a temperature range of 0 to +60°C and comes with an IP30-rated enclosure for protection against dust and foreign objects. The switch can be easily mounted on a DIN Rail and supports dual power inputs of 12 VDC to 24 VDC while maintaining low power consumption at just 9W. Ideal for engineers looking to enhance their network's performance and resilience, the Hirschmann BOBCAT Switch is a key component in modern industrial network solutions.

Brand	HIRSCHMANN
Degree of Protection	IP30
Dimensions (mm)	138H x 73W x 115D
Maximum Temperature (°C)	60
Minimum Temperature (°C)	0
Mounting Type	DIN Rail
No. of 100Mb Ports	8
No. of 1GB Ports	4
No. of Ethernet Ports	8
No. of Fiber Ports	4
No. of Ports	8 x 10/100BASE-TX RJ45, 4 x 100/1000 Fiber SFP
Nominal Power (W)	9
Operational Temperature Range (°C)	0 to +60
Power Consumption (W)	9
Rated Maximum Operational Voltage DC (V)	24
Rated Minimum Operational Voltage DC (V)	12
Rated Operational Voltage DC (V)	2 x 12 - 24
Series	BOBCAT
Standards and Approvals	CE, FCC, EN61131, EN62368-1
Switch Type	Switch - Managed
