Electromagnetic Capability |
20 V/m (80-2700 MHz), 10V/m (2.7-6 GHz)
1 kHz, 80% AM |
|
Electrostatic Discharge (kV) |
6 kV Contact Discharge, 8 kV Air Discharge |
|
Frequency Range (Hz) |
47 - 63 |
|
Mean Time Between Failure (MTBF) |
452 044 h |
|
Network Configuration |
any |
|
Operating Voltage Range |
100 - 240V AC |
|
Power Output in BTU (IT)/h |
Expected Max 44 (Without Media Modules) |
|
Relative Humidity |
5-90 % |
|
Resistance to Vibrations |
3.5 mm, 5–8.4 Hz, 10 cycles, 1 octave/min
1 g, 8.4–150 Hz, 10 cycles, 1 octave/min |
|
Software |
HiOS 09.4.01 |
|
Software Configuration |
Automatic Configuration Undo (roll-back), Text-based Configuration File (XML), Backup config on a remote server when saving, Clear config but keep IP settings, BOOTP/DHCP Client with Auto-Configuration, DHCP Server: per Port, DHCP Server: Pools per VLAN, , HiDiscovery, DHCP Relay with Option 82, USB-C Management support, Command Line Interface (CLI), CLI Scripting, CLI script handling over ENVM at boot, Full-featured MIB Support, Context-sensitive Help, HTML5 based Management |
|
Software Diagnostics |
Management Address Conflict Detection, MAC Notification, Signal Contact, Device Status Indication, TCPDump, LEDs, Syslog, Persistent Logging on ACA, Port Monitoring with Auto-Disable, Link Flap Detection, Overload Detection, Duplex Mismatch Detection, Link Speed and Duplex Monitoring, RMON (1,2,3,9), Port Mirroring 1:1, Port Mirroring 8:1, Port Mirroring N:1, Port Mirroring N:2, System Information, Self-Tests on Cold Start, Copper Cable Test, SFP Management, Configuration Check Dialog, Switch Dump |
|
Software Industrial Profiles |
IEC61850 Protocol (MMS Server, Switch Model), ModbusTCP |
|
Software Management |
Dual Software Image Support, TFTP, SFTP, SCP, LLDP (802.1AB), LLDP-MED, SSHv2, HTTP, HTTPS, IPv6 Management, Traps, SNMP v1/v2/v3, Telnet |
|
Software Miscellaneous |
Manual Cable Crossing, Port Power Down |
|
Software Redundancy |
Link Aggregation with LACP, Link Backup, Media Redundancy Protocol (MRP) (IEC62439-2), RSTP 802.1D-2004 (IEC62439-1), RSTP Guards |
|
Software Security |
MAC-based Port Security, Port-based Access Control with 802.1X, Guest/unauthenticated VLAN, Integrated Authentication Server (IAS), RADIUS VLAN Assignment, Denial-of-Service Prevention, LDAP, VLAN-based ACL, Ingress VLAN-based ACL, Basic ACL, Access to Management restricted by VLAN, Device Security Indication, Audit Trail, CLI Logging, HTTPS Certificate Management, Restricted Management Access, Appropriate Use Banner, Configurable Password Policy, Configurable Number of Login Attempts, SNMP Logging, Multiple Privilege Levels, Local User Management, Remote Authentication via RADIUS, User Account Locking, Password change on first login |
|
Software Switchng |
Independent VLAN Learning, Fast Aging, Static Unicast/Multicast Address Entries, QoS / Port Prioritization (802.1D/p), TOS/DSCP Prioritization, Interface Trust Mode, CoS Queue Management, Flow Control (802.3X), Egress Interface Shaping, Ingress Storm Protection, VLAN (802.1Q), VLAN Unaware Mode, GARP VLAN Registration Protocol (GVRP), Voice VLAN, GARP Multicast Registration Protocol (GMRP), IGMP Snooping/Querier per VLAN (v1/v2/v3), Unknown Multicast Filtering, Multiple VLAN Registration Protocol (MVRP), Multiple MAC Registration Protocol (MMRP), Multiple Registration Protocol (MRP) |
|
Software Time Synchronization |
Buffered Real Time Clock, SNTP Client, SNTP Server |
|
Transition Type |
2 kV Power Line, 2 kV Data Line |
|
Brand |
HIRSCHMANN |
|
Cable Length (m) |
0 - 100 |
|
Dimensions (mm) |
448W x 44H x 310D (without fixing bracket) |
|
Mounting Type |
19" Control Cabinet |
|
No. of Pins |
2 |
|
Operational Temperature Range (°C) |
-10 - 60 |
|
Power Consumption (W) |
Expected Max 13 (Without Media Modules) |
|
Standards |
CE, FCC, EN61131 |
|
Storage Temperature Range (°C) |
-20 - 70 |
|
Surge Voltage (kV) |
Power Line: 2 kV (Line/Earth), 1 kV (Line/Line); Data Line: 1 Kv |
|
Terminal Type |
2 x IEC Plug , 1 x Plug-In Terminal Block |
|
Weight (g) |
approx 3.85 k |
