W66 Industrial IP66 Switchgear

IPD MOTOR RATED ISOLATING SWITCH 3P 32A 500V LESS BASE, IP66 W66IS332LB

Product Code: W66IS332LB

Motor Rated Isolating Switch 3P without Base, IP66 - 32A, 500V This motor rated isolating switch is a 3-pole switch designed for use without a base. It has an IP66 rating, ensuring protection against dust and water ingress. The current rating of the switch is 32A, while the voltage rating is 500V. The switch is capable of accommodating cables with a maximum area of 16mm². It also features stainless steel fixings, providing durability and resistance to corrosion. Additionally, this isolating switch is padlockable for added security. Please note that it requires the W66B1 base for installation.

Technical Specifications

Brand IPD
Back Box Included No
Cover Style Light Grey
Degree of Protection IP66
Dimensions (mm) 101W x 101H x 109D
Gland Entries 2 x M25 + 1 x M32
Material Polycarbonate
Maximum Cable Cross Section (mm²) 16
No. of Poles 3
Rated Current (A) 32
Rated Voltage AC/DC (V) 500
Standards and Approvals IEC947-3/AS3133
