W66 Industrial IP66 Switchgear

IPD MOTOR RATED ISOLATING SWITCH 3P 32A 500V, IP66 W66IS332

Product Code: W66IS332

Motor rated isolating switch 3P with full size back box, IP66. Current rating at 32A, voltage rating at 500V. Max cable area 16mm² and stainless steel fixings, padlockable. This motor rated isolating switch is designed for three-phase applications and comes with a full-size back box. It has an IP66 rating, ensuring protection against dust and water ingress. The switch has a current rating of 32A and a voltage rating of 500V, making it suitable for various electrical systems. It can accommodate cables with a maximum area of 16mm². The switch is equipped with stainless steel fixings and is padlockable for added security.

Technical Specifications

Brand IPD
Back Box Included Yes
Cover Style Light Grey
Degree of Protection IP66
Dimensions (mm) 101W x 101H x 109D
Gland Entries 2 x M25 + 1 x M32
Material Polycarbonate
Maximum Cable Cross Section (mm²) 16
No. of Poles 3
Rated Current (A) 32
Rated Voltage AC/DC (V) 500
Standards and Approvals IEC947-3/AS3133
